详细描述
|
系列 |
尺寸 (mm) |
电感量 |
饱和电流 |
规格书 |
||
|
L |
W |
H |
||||
|
MS54S |
5.6±0.3 |
5.2±0.3 |
4.5±0.3 |
1uH - 220uH |
0.7A – 8.5A |
|
|
MS73S |
7.6±0.3 |
7.0±0.3 |
3.5±0.3 |
0.5uH - 100uH |
1.0A - 12A |
|
|
MS105S |
10.0±0.3 |
9.0±0.3 |
5.4±0.3 |
10uH - 470uH |
0.8A – 5.2A |
|
|
型号 |
电感量 [uH] |
直流电阻 [Ω] |
饱和电流 [A] |
替代 Bourns P/N |
|
MS54S-1R0N |
1.0 ±30% |
0.014 |
8.5 |
SRN6045-1R0Y |
|
MS54S-1R3N |
1.3 ±30% |
0.017 |
8.0 |
SRN6045-1R3Y |
|
MS54S-1R8N |
1.8 ±30% |
0.020 |
7.0 |
SRN6045-1R8Y |
|
MS54S-2R2N |
2.2 ±30% |
0.025 |
6.0 |
SRN6045-2R2Y |
|
MS54S-3R3N |
3.3 ±30% |
0.031 |
5.0 |
SRN6045-3R3Y |
|
MS54S-4R7N |
4.7 ±30% |
0.038 |
4.0 |
SRN6045-4R7Y |
|
MS54S-6R8N |
6.8 ±30% |
0.048 |
3.8 |
SRN6045-6R8Y |
|
MS54S-8R2N |
8.2 ±30% |
0.055 |
3.3 |
SRN6045-8R2Y |
|
MS54S-100M |
10 ±20% |
0.059 |
3.0 |
SRN6045-100M |
|
MS54S-150M |
15 ±20% |
0.096 |
2.3 |
SRN6045-150M |
|
MS54S-220M |
22 ±20% |
0.142 |
1.9 |
SRN6045-220M |
|
MS54S-330M |
33 ±20% |
0.188 |
1.5 |
SRN6045-330M |
|
MS54S-470M |
47 ±20% |
0.257 |
1.3 |
SRN6045-470M |
|
MS54S-680M |
68 ±20% |
0.351 |
1.0 |
SRN6045-680M |
|
MS54S-101M |
100 ±20% |
0.500 |
0.8 |
SRN6045-101M |
|
MS54S-221M |
220 ±20% |
1.180 |
0.7 |
SRN6045-221M |
|
型号 |
电感量 [uH] |
直流电阻 [Ω] |
饱和电流 [A] |
替代 Bourns P/N |
|
MS73S-R50N |
0.5±30% |
0.007 |
12.0 |
SRN8040-R50Y |
|
MS73S-1R0N |
1.0±30% |
0.010 |
11.0 |
SRN8040-1R0Y |
|
MS73S-1R5N |
1.5±30% |
0.011 |
8.2 |
SRN8040-1R5Y |
|
MS73S-2R2N |
2.2±30% |
0.013 |
7.4 |
SRN8040-2R2Y |
|
MS73S-3R3N |
3.3±30% |
0.021 |
5.5 |
SRN8040-3R3Y |
|
MS73S-3R6N |
3.6±30% |
0.022 |
5.3 |
SRN8040-3R6Y |
|
MS73S-4R7N |
4.7±30% |
0.024 |
4.7 |
SRN8040-4R7Y |
|
MS73S-6R8N |
6.8±30% |
0.033 |
4.2 |
SRN8040-6R8Y |
|
MS73S-8R2N |
8.2±30% |
0.045 |
4.0 |
SRN8040-8R2Y |
|
MS73S-100M |
10±20% |
0.050 |
3.4 |
SRN8040-100M |
|
MS73S-150M |
15±20% |
0.070 |
2.7 |
SRN8040-150M |
|
MS73S-220M |
22±20% |
0.100 |
2.2 |
SRN8040-220M |
|
MS73S-330M |
33±20% |
0.145 |
1.9 |
SRN8040-330M |
|
MS73S-470M |
47±20% |
0.190 |
1.5 |
SRN8040-470M |
|
MS73S-680M |
68±20% |
0.275 |
1.2 |
SRN8040-680M |
|
MS73S-101M |
100±20% |
0.400 |
1.0 |
SRN8040-101M |
|
型号 |
电感量 [uH] |
直流电阻 [Ω] |
饱和电流 [A] |
替代 Bourns P/N |
|
MS105S-100M |
10 ±20% |
0.029 |
5.20 |
SRN1060-100M |
|
MS105S-180M |
18 ±20% |
0.043 |
3.80 |
SRN1060-180M |
|
MS105S-220M |
22 ±20% |
0.053 |
3.40 |
SRN1060-220M |
|
MS105S-330M |
33 ±20% |
0.072 |
2.80 |
SRN1060-330M |
|
MS105S-470M |
47 ±20% |
0.11 |
2.30 |
SRN1060-470M |
|
MS105S-101M |
100 ±20% |
0.21 |
1.70 |
SRN1060-101M |
|
MS105S-151M |
150 ±20% |
0.30 |
1.35 |
SRN1060-151M |
|
MS105S-221M |
220 ±20% |
0.46 |
1.20 |
SRN1060-221M |
|
MS105S-331M |
330 ±20% |
0.62 |
0.90 |
SRN1060-331M |
|
MS105S-471M |
470 ±20% |
0.95 |
0.80 |
SRN1060-471M |
