Series

Dimensions (mm)

Inductance Range

Rated Current(A)

Coilcraft Series

Specification

L

W

H

MXAL4020

4.3

4.3

2.1

0.1uH - 2.2uH

6A - 33A

XAL4020

MXAL4030

4.3

4.3

3.1

0.47uH - 3.3uH

5.3A - 15A

XAL4030

MXAL5020

5.5

5.5

2.1

0.16uH - 1.5uH

4.6A - 18.7A

XAL5020

MXAL5030

5.5

5.5

3.1

0.16uH - 4.7uH

2.33A - 36.3A

XAL5030

MXAL5050

5.5

5.5

5.1

5.6uH - 10uH

5.4A - 7.2A

XAL5050

MXAL6030

6.6

6.4

3.1

0.18uH - 4.5uH

8A - 36A

XAL6030
