Series

Dimensions (mm)

Inductance Range

Rated Current

Specification

L

W

H

HCC102

14 max

14 max

9 max

0.51mH - 4.25mH

1A - 3A

HCC112

17.5 max

17.5 max

12.5 max

0.85mH - 6.80mH

2A - 5A

HCC114

21.5 max

22.5 max

13.2 max

1.70mH - 42.5mH

2A - 10A

HCC122

27.5 max

27.5 max

17.5 max

1.70mH - 42.5mH

2A - 10A

HCC142

32.5 max

33.1 max

19.7 max

1.70mH - 42.5mH

2A - 10A

HCC143

32.5 max

33.1 max

19.7 max

1.70mH - 42.5mH

2A - 10A

HCC152

41.8 max

43 max

25 max

1.70mH - 42.5mH

2A - 10A
