详细描述
Series |
Dimensions (mm) |
Inductance Range (uH) |
Rated Current (A) |
Specification |
||
L |
W |
H |
||||
CTRN1205 |
16.0 max |
7.5 max |
18.0 max |
14 - 100 |
1.5 – 4.0 |
|
CTRN1409 |
18.5 max |
14.5 max |
22.0 max |
16 - 110 |
3.0 – 7.5 |
Part Number |
Inductance [uH] |
DCR[mΩ] |
Rated Current [A] |
Cross Wurth P/N |
CTRN1205-140N |
14 |
15 |
4.0 |
744841414 |
CTRN1205-300N |
30 |
26 |
3.0 |
744841330 |
CTRN1205-470N |
47 |
40 |
2.0 |
744841247 |
CTRN1205-101N |
100 |
80 |
1.5 |
744841210 |
Part Number |
Inductance [uH] |
DCR[mΩ] |
Rated Current [A] |
Cross Wurth P/N |
CTRN1409-160N |
16 |
5.5 |
4.0 |
744842816 |
CTRN1409-320N |
32 |
11.0 |
3.0 |
744842632 |
CTRN1409-420N |
42 |
8.9 |
2.0 |
744842742 |
CTRN1409-650N |
65 |
14.3 |
1.5 |
744842565 |
CTRN1409-111N |
110 |
34.1 |
1.5 |
744842311 |
